| Suitable up to area : | 225 SQMTRS |
| Max : Intensity of Rainfall : | 75 mm/hr |
| Working Principle : | Cohesive Force & Centrifugal force |
| Operating Pressure : | Less than 2 feet of head (0.060kg/cm2) |
| Capacity : | 225 LPM |
| Filter Element : | SS-304 Screen |
| Mesh Size : | 250 Microns |
| Inlet : | 110 MM |
| Clean Water Outlet : | 75 MM |
| Drain Outlet : | 90 MM |
| Housing : | High Density Polyethylene |
| Efficiency of Filter : | Above 90% |
| Source of Power : | Gravity |
The characteristic features of FL Series Dual Intensity RWH Filter is its capacity to take up the load up to 10 to 225 square meters of Roof area with variable intensity of rainfall of 5 to 75 mm/hour with a discharge capacity of 10 To 225 Liters per minute. This filter can be conveniently used for Harvesting Rainwater for Individual households, Schools, Apartments, institutions, and Commercial Buildings of Medium sizes.
